Experience ultimate convenience with Brink’s Home Security innovative Push Pull Rotate technology, allowing you to open doors with an elbow, hip, or finger. Built on a commercial-grade chassis for durability, this modern satin nickel lockset is perfect for high-traffic residential entryways. Installation is quick and easy, requiring only a Phillips screwdriver to upgrade your home's functionality.
Experience ultimate convenience with Brink’s Home Security innovative Push Pull Rotate technology, allowing you to open doors with an elbow, hip, or finger. Built on a commercial-grade chassis for durability, this modern satin nickel lockset is perfect for high-traffic residential entryways. Installation is quick and easy, requiring only a Phillips screwdriver to upgrade your home's functionality.
Door Handing
Universal
Interior / Exterior
Exterior
Minimum Door Thickness
1.375 in
Keyway
No Keyway
Security/ANSI Grade
ANSI Grade 3 (Good)
Features
Easy Installation
Door Lock Style
Modern
Backset Size
Adjustable
Lever Material
Zinc
Number of Pins
5
Deadbolt Strike
Round Corner
Hardware Finish Family
Nickel
Door Locks & Knobs Product Type
Keyed Levers
Total Number of Keys Included
2
Lock Type
Keyed Entry
Electronic / Mechanical
Mechanical
Single or Double Cylinder Deadbolt
Single
Application Type
Passage
Deadbolt Type
Single Cylinder Deadbolt
Finish
Satin Nickel
Commercial/Residential
Residential
Lever Style
Straight
Knob / Lever Housing Width
3.75 in
Deadbolt Strike Width
2 in
Knob / Lever Bore Hole Diameter
2.125 in
Deadbolt Throw Length
1 in
Deadbolt Strike Height
2.75 in
Knob / Lever Strike Height
2.25 in
Knob / Lever Throw Length
0.50 in
Knob / Lever Strike Width
1.71 in
Assembled Depth
1.75 in
Lever Grip Length
4.65 in
Deadbolt Bore Hole Diameter
2.125 in
Deadbolt Trim Ring Diameter
2.57 in
Deadbolt Cross Bore Diameter
1 in
Assembled Width
6.125 in
Maximum Door Thickness
1.75 in
Cross Bore Diameter
1 in
Projection
1.75 in
Knob / Lever Housing Height
3 in
Assembled Height
3.75 in
Dimensions
4.5 × 10.88 × 9.13 in
Weight
4.2 lbs
