Elevate your home's curb appeal with this elegant black handleset featuring a classic Waverlie lever trim. Built to ANSI/BHMA Grade 3 standards, this durable zinc construction provides reliable security and a sophisticated finish for residential doors.
Elevate your home's curb appeal with this elegant black handleset featuring a classic Waverlie lever trim. Built to ANSI/BHMA Grade 3 standards, this durable zinc construction provides reliable security and a sophisticated finish for residential doors.
| Door Handing | Universal |
| Interior / Exterior | Interior/Exterior |
| Minimum Door Thickness | 1.375 in |
| Keyway | KW1 |
| Security/ANSI Grade | ANSI Grade 3 |
| Door Lock Style | Classic |
| Backset Size | Adjustable |
| Deadbolt Strike | Full Round |
| Hardware Finish Family | Black |
| Door Locks & Knobs Product Type | Keyed Handlesets |
| Material | Zinc |
| Keying Type | Keyed Different |
| Total Number of Keys Included | 2 |
| Lock Type | Keyed Entry |
| Electronic / Mechanical | Mechanical |
| Knob / Lever Strike | Round Corner |
| Application Type | Privacy |
| Deadbolt Type | Single Cylinder Deadbolt |
| Finish | Black |
| Commercial/Residential | Residential |
| Lever Style | Straight |
| Handleset Product Type | 1 Piece Front & Back |
| Knob / Lever Housing Width | 2.5 in |
| Deadbolt Strike Width | 1 in |
| Outside Key Plate Width | 2.375 in |
| Outside Bottom Handle Plate Length | 2.5625 in |
| Inside Top Plate Length | 2.5 in |
| Knob / Lever Bore Hole Diameter | 2.125 in |
| Deadbolt Throw Length | 1 in |
| Outside Key Plate Length | 3.625 in |
| Handle Grip Length | 7 in |
| Inside Top Plate Width | 2.5 in |
| Deadbolt Strike Height | 2.25 in |
| Outside Top Handle Plate Length | 4.375 in |
| Knob / Lever Strike Height | 2.25 in |
| Knob / Lever Throw Length | 0.5 in |
| Knob / Lever Strike Width | 2.25 in |
| Assembled Depth | 4 in |
| Lever Grip Length | 4.75 in |
| Knob / Lever Housing Height | 2.5 in |
| Deadbolt Bore Hole Diameter | 1 in |
| Deadbolt Trim Ring Diameter | 2.5 in |
| Outside Top Handle Plate Width | 2.75 in |
| Outside Bottom Handle Plate Width | 1.625 in |
| Deadbolt Cross Bore Diameter | 2.125 in |
| Assembled Width | 4 in |
| Maximum Door Thickness | 2 in |
| Projection | 2 in |
| Knob / Lever Cross Bore Diameter | 2.125 in |
| Assembled Height | 18 in |
| Weight | 3.3 lbs |
| Length | 18 in |
| Width | 3.3 in |
| Height | 4 in |
