Enhance your double door entrance with the elegant and contemporary Delaney Avino dummy handleset in a sleek satin nickel finish. Designed for use on inactive doors, this versatile hardware features a split trim design to accommodate both new construction and remodeling projects.
Enhance your double door entrance with the elegant and contemporary Delaney Avino dummy handleset in a sleek satin nickel finish. Designed for use on inactive doors, this versatile hardware features a split trim design to accommodate both new construction and remodeling projects.
Door Handing
Universal
Interior / Exterior
Interior/Exterior
Minimum Door Thickness
1.375 in
Security/ANSI Grade
ANSI Grade 3 (Good)
Features
Easy Installation, Adjustable Backset
Door Lock Style
Classic
Backset Size
Adjustable
Deadbolt Strike
Round Corner
Hardware Finish Family
Nickel
Door Locks & Knobs Product Type
Keyed Handlesets
Material
Zinc
Keying Type
Keyed Alike
Total Number of Keys Included
2
Knob Style
Flat Ball
Lock Type
Keyed Entry
Electronic / Mechanical
Mechanical
Knob / Lever Strike
Full Round
Included
Mounting Hardware, Hardware, Installation Instructions, Drilling Template, Self Guiding Screws
Application Type
Dummy
Deadbolt Type
Single Cylinder Deadbolt
Finish
Satin Nickel
Commercial/Residential
Residential
Handleset Product Type
2 Piece Front & Back
Knob / Lever Housing Width
2 in
Deadbolt Strike Width
1 in
Outside Key Plate Width
2.5 in
Outside Bottom Handle Plate Length
11.5625 in
Inside Top Trim Length
2.5 in
Knob / Lever Bore Hole Diameter
1 in
Deadbolt Throw Length
1 in
Outside Key Plate Length
2.5 in
Handle Grip Length
8.41 in
Inside Top Plate Width
2.5 in
Deadbolt Strike Height
2.25 in
Outside Top Handle Plate Length
2.5 in
Knob / Lever Strike Height
2.25 in
Knob Diameter
2.25 in
Knob / Lever Throw Length
0.5 in
Knob / Lever Strike Width
1.75 in
Assembled Depth
3 in
Deadbolt Bore Hole Diameter
2.13 in
Deadbolt Trim Ring Diameter
1 in
Outside Top Handle Plate Width
2.5 in
Outside Bottom Handle Plate Width
1.5625 in
Deadbolt Cross Bore Diameter
2.125 in
Assembled Width
2.625 in
Maximum Door Thickness
1.75 in
Projection
2.14 in
Knob / Lever Cross Bore Diameter
2.125 in
Knob / Lever Housing Height
2.5625 in
Assembled Height
11.5625 in
Dimensions
12 × 6 × 4 in
Weight
2 lbs
